Hydac 0030 D 003 ON Replaces the Hydac 1263542
Hydac 0030 D 003 ON Pressure Filter | Replaces the Hydac 1263542
0030 D 003 ON
Hydac
Hydac 1263542
Hydac
Hydac 1263542
Brand:
Hydac
Description
The original Hydac 0030 D 003 ON Betamicron® pressure filter has been optimised with respect to filtration performance, in fluid cleanliness, lower ΔP/Q, pleat and element protection while handling and operating, and high stability level throughout its life. These elements offer a superior level of optimisation of separation efficiency, service life and differential pressure versus flow rate.
As a complete element package, the innovative characteristics of this technology have a very positive impact on the differential pressure of the elements and a high degree of filtration efficiency and performance.
Regular price
¥904.00
Unit price
per
Germany
8421.23.00
0.11 kg
0.0005 m³
Italy
8421.99.90
0.22 kg
United Kingdom
8421.99.90
Description
The original Hydac 0030 D 003 ON Betamicron® pressure filter has been optimised with respect to filtration performance, in fluid cleanliness, lower ΔP/Q, pleat and element protection while handling and operating, and high stability level throughout its life. These elements offer a superior level of optimisation of separation efficiency, service life and differential pressure versus flow rate.As a complete element package, the innovative characteristics of this technology have a very positive impact on the differential pressure of the elements and a high degree of filtration efficiency and performance.
Specification
| Style | Pressure Filter |
| Media | Glass Fiber |
| Efficiency 1 | 3µ @ β200 |
| Efficiency 2 | 5µ @ β1000 |
| Outer Diameter | 52.0 mm |
| Inner Diameter | 22.2 mm |
| Length | 169.0 mm |
| Δ Collapse Pressure | 20 bar |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
Hydac Product
Genuine Hydac 0030 D 003 ON
Inspected to ISO 9001:2015
